ROCKFORD FOSGATE PRIME SERIES 12" 4 OHM DUAL VC SUBWOOFER 500W PEAK RF-R2D4-12

R2D412
$124.99
In stock
1
Product Details
UPC: 780687332563
Brand: ROCKFORD FOSGATE
  • 12 AWG compression terminals
  • Mica injected polypropylene cone
  • Anodized aluminum voice coil former
  • Optimized for both sealed and vented enclosures
  • Dimensions: 14.8"x14.8"x7.5"

Rockford Fosgate Prime Series 12" 4 Ohm Dual VC Subwoofer 500W Peak RF-R2D4-12

Car Audio Fanatics wanting big bass can rely on the Prime R2D4-12 subwoofer. This 12" subwoofer handles 250 Watt RMS and the 4-Ohm Dual Voice Coil design lets you to wire them in various configurations. These drivers can pump out the bass due to their mica injected polypropylene cone, and their stamp-cast baskets with spider venting - typically reserved for more expensive models - keep the motor running cool! These R2 subwoofers are optimized for sealed and vented enclosures.

This Listing Includes:

(1) 12" 4 Ohm Dual VC Subwoofer 500W Peak

Features:

  • 12 AWG compression terminals
  • Linear spider with embedded 16 AWG tinsel leads
  • Mica injected polypropylene cone
  • Anodized aluminum voice coil former
  • Optimized for both sealed and vented enclosures
  • StampCast basket with integrated spider venting
  • Integrated PVC trim ring

Specifications:

  • Magnet Weight (oz): 47.7 oz
  • Size: 12"
  • Voice Coil Diameter: 2"
  • Nominal Impedance: Dual 4-Ohm
  • Speaker Connector: Dual 12 AWG compression
  • Mounting Depth: 5.067 in
  • Shipping Weight: 9.9 Lbs
  • Qts: 0.60
  • Qms: 7.33
  • Qes: 0.66
  • Vas (Liters): 68.8
  • Le (mH): 3.9
  • Power Handling (Watts RMS): 250 Watts RMS - 500 Watts Max
  • SPL (dB @ 1w/1m): 89
  • Fs (Hz): 34.9
  • Xmax (mm): 6.5
  • Cutout Diameter: 11.25 in
  • Woofer Displacement: 0.046 cu. ft.
  • CEA-2031 Compliant: Yes
  • Re (Ohms): 7.17
  • Sd (cm2): 539.1
  • Subwoofer Type: Standard
  • Voice Coil Type: Dual Voice Coil
  • Sealed Box Volume (Vb): 1.02 cu. ft.
  • Vented Box Volume (Vb): 1.79 cu. ft.

Dimensions:

  • 14.8"x14.8"x7.5"
