ROCKFORD FOSGATE PRIME SERIES 10" 2 OHM DUAL VC SUBWOOFER 500W PEAK RF-R2D2-10

R2D210
$112.99
In stock
1
Product Details
Brand: ROCKFORD FOSGATE
  • 12 AWG compression terminals
  • Mica injected polypropylene cone
  • Anodized aluminum voice coil former
  • Optimized for both sealed and vented enclosures
  • Dimensions: 12.5"x12.5"x6.8"

Rockford Fosgate Prime Series 10" 2 Ohm Dual VC Subwoofer 500W Peak RF-R2D2-10

Car Audio Fanatics wanting big bass can rely on the Prime R2D2-10 subwoofer. This 10†subwoofer handles 250 Watt RMS and the 2-Ohm Dual Voice Coil design lets you to wire them in various configurations. These drivers can pump out the bass due to their mica injected polypropylene cone, and their stamp-cast baskets with spider venting - typically reserved for more expensive models - keep the motor running cool! These R2 subwoofers are optimized for sealed and vented enclosures.

This Listing Includes:

(1)10" 2 Ohm Dual VC Subwoofer 500W Peak

Features:

  • 12 AWG compression terminals
  • Linear spider with embedded 16 AWG tinsel leads
  • Mica injected polypropylene cone
  • Anodized aluminum voice coil former
  • Optimized for both sealed and vented enclosures
  • StampCast basket with integrated spider venting
  • Integrated PVC trim ring

Specifications:

  • Magnet Weight (oz): 43 oz
    • Size: 10"
    • Voice Coil Diameter: 2"
    • Nominal Impedance: Dual 2-Ohm
    • Speaker Connector: Dual 12 AWG compression
    • Mounting Depth: 4.319 in
    • Shipping Weight: 8.8 Lbs
    • Qts: 0.47
    • Qms: 6.93
    • Qes: 0.50
    • Vas (Liters): 39
    • Le (mH): 3.9
    • Power Handling (Watts RMS): 250 Watts RMS - 500 Watts Max
    • SPL (dB @ 1w/1m): 86.9
    • Fs (Hz): 34.6
    • Xmax (mm): 6.5
    • Cutout Diameter: 9.125 in
    • Woofer Displacement: 0.039 cu. ft.
    • CEA-2031 Compliant: Yes
    • Re (Ohms): 3.84
    • Sd (cm2): 339.8
    • Subwoofer Type: Standard
    • Voice Coil Type: Dual Voice Coil
    • Sealed Box Volume (Vb): 0.59 cu. ft.
    • Vented Box Volume (Vb): 1.4 cu. ft.

                                                  Dimensions:

                                                  • 12.5"x12.5"x6.8"
